Planning a new home's wiring, renovating an old flat, or simply upgrading your old switch boards? One question often comes up for homeowners and interior designers: which modular switch-board is right for which room?
The answer is not the same for every space. Each room has different power needs, a different number of switches, and its own safety requirements. This guide breaks it down room by room, so you can plan clearly before your electrician steps in.
Pro Tip: Decide how many switches you need in each board before construction starts. Changing it after the walls are done can be difficult and expensive.
The biggest benefit of a modular switch board is flexibility. You can choose how many slots you need and what goes into each one.. A bedroom has different electrical demands than a kitchen. A home office wired for 2020 cannot cope with the multi-device reality of 2026. Planning per room ensures you do not under-provision a space (leading to extension cord hazards) or over-engineer it (wasting budget).
The Fybros modular switch board range is available in 2, 4, 6, 8, 10, and 12 module configurations. For most living spaces, a 12 modular switch board is the single most versatile format. It is large enough to consolidate all connection points in one location, yet compact enough to fit within a standard 4" x 8" wall opening.
The master bedroom is typically the highest-density room for wiring points. A standard modern master bedroom requires:
• 2 x Fan regulators (2 modules each = 4 modules)
• 1 x Light dimmer (2 modules)
• 2 x 5-pin sockets (16A) for AC and television (3 modules each = 6 modules)
• Recommendation: One 12-module board covers all primary points. Add a secondary 4-module board near the bed for USB-C charger and reading lamp switch.
The living room is your home's electrical hub, with a ceiling fan, main light, accent lighting, entertainment system, and increasingly, smart home controls. A recommended layout for a 12-module board in the living room:
• 4 single switches (light, fan, accent, passage) = 4 modules
• 1 x 16A socket for AC = 3 modules
• 1 x 5-pin socket for TV/entertainment = 3 modules
• 1 x dual USB-C charger = 2 modules
Total: 12 modules exactly. The Fybros 12 Modular Switch Board handles this configuration with precision, and its premium finish variants complement contemporary living room interiors.
Kitchens demand high-current appliances and an emphasis on safety near moisture sources. Plan for:
• 1 x 16A socket for microwave (3 modules)
• 1 x 16A socket for refrigerator (3 modules)
• 1 x 6A socket for mixer or toaster (1 module)
• 1 x switch for exhaust fan (1 module)
• 1 x switch for under-cabinet light (1 module)
• 1 x spare 6A socket (1 module)
Total: 10 modules. An 8 or 10-module board works for a compact kitchen; a 12-module board gives room to add a smart relay for future automation. Always place kitchen boards at a safe height and distance from the sink as per NBC 2016 guidelines.
Remote work has permanently changed home electrical requirements. A 2026-ready home office needs:
• 2 x 5-pin sockets for desktop/monitor = 6 modules
• 1 x 16A socket for UPS = 3 modules
• 1 x dual USB-A/C charger = 2 modules
• 1 x switch for task light = 1 module
Total: 12 modules. A single Fybros 12-module board elegantly consolidates your entire home office power wall.
Bathrooms require IP44-rated modules and enclosures. Standard wiring points include: geyser switch (1), exhaust fan switch (1), mirror light switch (1), shaver socket (1 module, BS-standard shaver socket). A 4 or 6-module IP44-rated board is typically sufficient. Fybros offers weather-resistant modular options for semi-exposed wet-area installations.
|
Room |
Min. Modules |
Recommended Board |
Notes |
|
Master Bedroom |
10–12 |
12 Module |
Add 4-module beside bed |
|
Living Room |
10–12 |
12 Module |
Smart-home ready |
|
Kitchen |
8–10 |
10 Module |
IP44 near sink |
|
Home Office |
10–12 |
12 Module |
UPS + USB priority |
|
Bathroom |
4–6 |
6 Module |
IP44 rated essential |
|
Balcony/Utility |
2–4 |
4 Module |
Weatherproof option |
Fybros's modular switch board range is BIS-certified (IS:3854 and IS:1293) and available in multiple configurations and finishes, making it the most versatile choice for every room in your home. Explore the full range on the Fybros wiring devices page and plan your room-by-room wiring with confidence.
