Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights
Keya Surface Panel Lights

Keya Surface Panel Lights

M.R.P. 440
Product Code FLS 7001
M.R.P. 440
Product Code FLS 7002
M.R.P. 440
Product Code FLS 7003
M.R.P. 760
Product Code FLS 7004
M.R.P. 760
Product Code FLS 7005
M.R.P. 760
Product Code FLS 7006
M.R.P. 1060
Product Code FLS 7007
M.R.P. 1060
Product Code FLS 7008
M.R.P. 1060
Product Code FLS 7009
M.R.P. 1460
Product Code FLS 7010
M.R.P. 1460
Product Code FLS 7011
M.R.P. 1460
Product Code FLS 7012
M.R.P. 440
Product Code FLS 7016
M.R.P. 440
Product Code FLS 7017
M.R.P. 440
Product Code FLS 7018
M.R.P. 760
Product Code FLS 7019
M.R.P. 760
Product Code FLS 7020
M.R.P. 760
Product Code FLS 7021
M.R.P. 1060
Product Code FLS 7022
M.R.P. 1060
Product Code FLS 7023
M.R.P. 1060
Product Code FLS 7024
M.R.P. 1460
Product Code FLS 7025
M.R.P. 1460
Product Code FLS 7026
M.R.P. 1460
Product Code FLS 7027

Size (mm) 90 X 27

Type Frame Less

Size (mm) 90 X 27

Type Frame Less

Size (mm) 90 X 27

Type Frame Less

Size (mm) 120 X 27

Type Frame Less

Size (mm) 120 X 27

Type Frame Less

Size (mm) 120 X 27

Type Frame Less

Size (mm) 155 X 27

Type Frame Less

Size (mm) 155 X 27

Type Frame Less

Size (mm) 155 X 27

Type Frame Less

Size (mm) 190 X 27

Type Frame Less

Size (mm) 190 X 27

Type Frame Less

Size (mm) 190 X 27

Type Frame Less

Size (mm) 90 X 27

Type Frame Less

Size (mm) 90 X 27

Type Frame Less

Size (mm) 90 X 27

Type Frame Less

Size (mm) 120 X 27

Type Frame Less

Size (mm) 120 X 27

Type Frame Less

Size (mm) 120 X 27

Type Frame Less

Size (mm) 155 X 27

Type Frame Less

Size (mm) 155 X 27

Type Frame Less

Size (mm) 155 X 27

Type Frame Less

Size (mm) 190 X 27

Type Frame Less

Size (mm) 190 X 27

Type Frame Less

Size (mm) 190 X 27

Type Frame Less

Download Catalogue

Product Detail

Built in Driver, Surge Protection upto 2.5 KV

Recyclables, Working Temperture -10°C to 50°C,

Housing : Aluminium, Power Factor : ≥0.85

Working Voltage AC 220-240V, 50/60Hz

30000 Hours Life,Dimension: 120mm X120mm X 27mm, No Harmful Radiation, NO UV/IR

Anti Glare Diffuser, CRI (Ra) ≥ 80, 90 Lumens Per Watt

Technical Specification

Suitable for Mall, Shops and offices, Restaurants, Hotel Guest Rooms
Mounting type                                  Ceiling light







Wattage 6W, 12W, 18W, 24W
Rated input voltage                                  220-240V
Frequency 50/60 Hz
Operating temperature -10 °C to 45 °C
Power factor > 0.9







Wattage 6W, 12W, 18W, 24W
Rated input voltage                                  220-240V
Frequency 50/60 Hz
Operating temperature -10 °C to 45 °C
Power factor > 0.9







Fixture Shape Round, Square
Material Polycarbonate
Body colour White
Diffuser shape                                  Round, Square
Diffuser transparency Transparence
Driver Independent
Mounting arrangement Ceiling light







Cut Size (mm) N/A
Dimension (D x H)                                  "6W-90 X 27
12W-120 X 27
18W-155 X 27
24W-190 X 27"







Colour Rendering Index (CRI) >80
Colour Temperature Cool White-6500K, Warm White-2800K, Natural White-4200K
Light Effect Cool White, Warm White, Nature White
Lumen 90







IP rating IP20
High Voltage Protection Upto 440V
Mercury content                                  No mercury







Warranty                                  2 Year
